HPDC (High-Pressure Die Casting) Draft Angle Calculator
Welcome to the HPDC (High-Pressure Die Casting) Draft Angle Calculator! This tool is designed to help you determine the required draft angle for mold injection parts in HPDC processes. By considering the part height and material, you can ensure successful molding with minimal defects and smooth ejection of the finished part.
How to use?
- Part Height (L) :
Input the height of your part in the provided field. The height should be measured from the parting line (PL) of the mold.
- Part Material :
Choose the appropriate material from the available options in the dropdown menu. Different materials have varying properties that can affect the required draft angle.
Remember that the draft angle recommendation provided by this calculator is a general guideline. Other factors, such as the complexity of the part's geometry, surface finish requirements, and mold design, may also influence the optimal draft angle. Consult with a professional or refer to specific design guidelines for a comprehensive assessment.
{[{ responseError.message }]}
Results
We apologize for any inconvenience caused by the issue in calculating your data. Please try again later.
- Part Height (L) : {[{ output.height }]} mm
- Part material : {[{ output.material }]}
- Inside Surface Angle (A) : {[{ output.insideSurfaceAngle }]} degree
- Outside Surface Angle (A) : {[{ output.outsideSurfaceAngle }]} degree
- Hole Angle (A) : {[{ output.holeAngle }]} degree
- Inside Surface Distance (D) : {[{ output.insideSurfaceDistance }]} mm
- Outside Surface Distance (D) : {[{ output.outsideSurfaceDistance }]} mm
- Hole Distance (D) : {[{ output.holeDistance }]} mm
